TS-3XX TEMPERATURE SENSOR
Temperature SensorsIt precisely measures the temperature values in the environment;
- Accurate and Precise Measuring
- Long Operating Life
- Easy Assembling
- IP 67 Plastic Case
** Sensor cable length can be changed (0-10m) according to demand.
** Metal Probe length can be selected as 50mm or 100mm.
| Product Informations | |
|---|---|
| Product Name | TS-3XX Temperature Sensor |
| Sensor Type | NTC-10K / NTC-30K / PT-100 / PT-1000 |
| Measuring Range | (-40)–(+80)°C |
| Product Code | Sensor Type | Sensitivity | Accuracy |
|---|---|---|---|
| TS-311 | NTC-10K | ± 0,1 °C | ± 0,5 °C |
| TS-312 | NTC-30K | ± 0,1 °C | ± 0,5 °C |
| TS-321 | PT-100 | ± 0,1 °C | ± 0,5 °C |
| TS-331 | PT-1000 | ± 0,1 °C | ± 0,1 °C |
| Sensor Type | Beta Value |
|---|---|
| NTC-10K | B25/85 – 3435K |
| NTC-30K | B0/50 – 3892K |
| Dimensions | |||||
|---|---|---|---|---|---|
| A | B | C | a | b | c |
| 135 mm | 58 mm | 35 mm | 64 mm | 50 mm | 6 mm |
