TS-31X TEMPERATURE SENSOR
Temperature SensorsIt precisely measures the temperature values in the environment;
- Accurate and Precise Measuring
- Long Operating Life
- Easy Assembling
- IP 67 Plastic Case
** Sensor cable length can be changed (0-10m) according to demand.
** Metal Probe length can be selected as 50mm or 100mm.
| Product Informations | |
|---|---|
| Product Name | TS-31X Temperature Sensor |
| Sensor Type | NTC 10 K / NTC 30 K |
| Sensor | Temperature |
|---|---|
| Measuring Range | (-40) – (+80)°C |
| Sensitivity | ± 0,1 °C |
| Accuracy | ± 0,5 °C |
| Product Code | Sensor Type | Beta Value |
|---|---|---|
| TS-311 | NTC 10 K | B25/85-3435K |
| TS-312 | NTC 30 K | B0/50-3892K |
| Dimensions | |||||
|---|---|---|---|---|---|
| A | B | C | a | b | c |
| 135 mm | 58 mm | 35 mm | 64 mm | 50 mm | 6 mm |
