EG-6XX DIGITAL DISPLAY
Digital DisplayIt enables the values in the environment to be displayed by means of sensors.
- Accurate and Precise Measuring
- 3 Analog Input
- Durable and Handy Design
- Long Operating Life
- Easy Assembling
- IP 67 Plastic Case (Not Including Sensor)
- Switchable Sensor Inputs on Demand
| Product Informations | |
|---|---|
| Product Name | EG-601 Temperature Humidity Carbon dioxide Display |
| Input | 12-24 V DC |
| Sensor | Temperature | Humidity | Carbon dioxide |
|---|---|---|---|
| Measuring Range | 0-50 °C (-20)-(+80) °C | 0-100 % | 0 – 5.000 ppm 0 – 10.000 ppm |
| Sensitivity | ± 0,1 °C | ± % 1 | ± 10 ppm |
| Accuracy | ± 0,3 °C | ± % 3 | ± 50 ppm + %2 |
| Dimensions | |||||
|---|---|---|---|---|---|
| A | B | C | a | b | c |
| 152 mm | 109 mm | 60 mm | 115 mm | 65 mm | 113 mm |
